V-MAX™ Grid Coil Cleaning

Designed for medium-to-large Air Handling Unit installation

V-MAX for Coil

Flexible and Simple Installation

  • 1.Scalable design to meet any plenum size
  • Lamps can be easily mounted on vertical supports
  • Ballast is designed to easily mount in vertical support strut
  • Negligible pressure drop
  • Low power consumption with universal voltage
  • 90° booted connector standard with 1.5 meter lamp leads
  • Straight connector standard with 3 meter lamp leads
  • Available in 53.34 cm, 83.82 cm, 121.92 cm and 154.94 cm lamps
Download Brochure

V-MAX™ Coil Cleaning

Designed for in-duct use

V-MAX

Flexible and Simple Installation

  • Designed for duct-mounting parallel to the airstream providing optimum UV exposure
  • Prewired lamp connection reduced installation time
  • Low power consumption with universal voltage
  • Available in 53.34 cm, 83.82 cm, 121.92 cm and 154.94 cm lamps
Download Brochure

Optional Lamp Clip Kits

34-1063 Two Snap-in Lamp Clips

V-MAX™ Grid Lamp Clip Kit - Snap In (2 Poly)

Part No. 34-1063

Included with the V-MAX™ Grid

Two Metal Clips for the V-MAX™

V-MAX™ Lamp Clip Kit - (2 Metal)

Part No. 40-2011

Included with V-MAX™

2 Metal and 1 End Magnetic Clip

V-MAX™ Lamp Clip Kit - Magnetic (2 Metal, 1 End)

Part No. 23-1068

Magenetic Plastic Clips - 2 Poly and 1 End

V-MAX™ Lamp Holder Magnetic Plastic Clip (2 Poly & 1 End)

Part No. 23-1069

23-1069-05 2 Poly Magnetic Lamp Clips

V-MAX™ Lamp Clip Kit - Magnetic (2 Poly)

Part No. 23-1069-05

23-1069-10 Magnetic Lamp Clip Set

V-MAX™ Lamp Clip Set - Magnetic (1 Poly, 1 End)

Part No. 23-1069-10

Two Magnetic Metal Clips

V-MAX™ Lamp Clip Kit - Magnetic (2 Metal)

Part No. 23-1063

Clip Features

Clip Features

Both snap-in and magnetic clips are designed to hold either the end cap or the bulb

Tech Specs

Input Voltage Lamp Configuration
53.34 cm Dual 53.34 cm 83.82 cm Dual 83.82 cm 121.92 cm 154.94 cm
120 0.45 0.90 0.75 1.45 1.24 1.3
208 0.30 0.60 0.45 0.90 0.75 0.80
240 0.25 0.50 0.40 0.80 0.65 0.70

Designed for use with 120, 208 and 240 VAC input. Approximate current draw (in Amps).

  • Rated for temperature 30°F — 135°F (-1°C — 57°C)
  • RH: up to 95% non condensing
  • 90° boot lamp connectors for ease of installation; boot extends over lamp endcap providing high level of moisture resistance.

Regulatory Approvals

ETL listed to UL/Canadian standards:

  • UL 1598/CSA 22.2 250
  • UL 1995/CSA 22.2 236
  • UL 153/CSA 22.2 12

CE Certified
